Glowforge Supplemental Laser Enclosure Kit - Coming Soon

$565.00

Clearview's supplemental enclosure for the Gweike Cloud is designed to offer added protection from fumes produced by laser engraving and cutting. Some have suggested that the fume and smoke mitigation of the Gweike Cloud could be better. Clearview has developed performance enclosure solutions for many machines leading to a healthier workspace. We can improve control over the smells, fumes, and smoke in your workspace with our supplemental enclosure. This product is currently under development. If you have a Gweike Cloud that you would like to enclose, reach out to us at contact@clearviewplastic.com

Information from Our D1 enclosure is below:

Key Features:

  1. Universal Fit for XTool D1: With dimensions of 24" wide x 24" deep x 16" tall (63cm x 68.5cm x 40.5cm), the enclosure is specifically designed to accommodate the XTool D1 laser engraver, ensuring a perfect fit.

  2. Commercial Grade Construction: The enclosure boasts 1/4" thick panels for enhanced stability and durability, providing a robust and reliable protective enclosure for your XTool D1.

  3. Hood Mounted Lightburn Camera: Equipped with a USB camera mounted on the hood, our enclosure enables accurate part alignment with Lightburn tracing, enhancing precision and efficiency.

  4. Air Assist Compatibility: The enclosure features two access points for convenient wire feeding and air assist tubing integration, allowing seamless operation with air assist systems.

  5. Multiple Exhaust Options: The enclosure offers 4" exhaust options, providing flexibility to adapt to different ventilation setups and requirements.

  6. Extendable Design: Easily extend the enclosure by adding a second unit, providing a simple and effective way to expand the working area as needed.

  7. Expandable Configuration: Customize your setup by choosing the side for the exhaust vent to best fit your workspace. Additionally, you have the option to add a second fan for increased exhaust capacity.

Clearview enclosures are made in California, by a small business that understands the needs of crafters and carries genuine appreciation for your support.

Enclosure Assembly Instructions

Extended Enclosure Assembly Instructions

Blazecut Instructions





Customizable:

  • ✅Spec and customize your build with a rapsheet of customizations. The base enclosure configuration includes 1/4" panels, parts and hardware for assembly, and a bracket to add your exhaust system. If you need more functionality, we have tailor fit several options to fit your use case. Here are some of the options we offer:
  • ✅Spectrometer tested UV Blocking - Laser shielding panels have 1% light transmission at the 450nm wavelength. (The wavelength that a diode laser operates at)
  • ✅Exhaust options - Clearview offers a compact exhaust fan option that are small in form factor yet powerful in moving air with fan power up to 200cfm. Or, bring your own exhaust system and easily hook up your 4" hose to our fitted exhaust bracket.
  • ✅120v LED Lighting kit -  Easily mount lighting into your enclosure to light up your workspace.
  • ✅Fitted MDF Spoilboard - Get an attachable, easy to use spoilboard for your laser that fits the footprint of your enclosure.
  • ✅Pro Grade Accessory kit - The Professional accessory kit includes an assortment of parts to add functionality to your enclosure. (1" Lift kit blocks, Aluminum door hardware, Heavy Duty Stainless Steel hardware)





Why Choose XTool D1 Enclosure?

Laser engraving involves the production of smoke, soot, and fumes that can pose health risks. Many laser engraver manufacturers do not include enclosures, making it a challenging and expensive add-on. Our enclosure is specifically designed to contain and mitigate these hazards effectively. By incorporating an exhaust port, it offers optimal fume containment. If you plan to engrave indoors, the XTool D1 enclosure is a necessary upgrade to ensure a safe working environment.





What to Expect:

Our enclosure is precisely tailored for the XTool D1 laser engraver. The CNC-cut panels ensure accurate sizing, while the 3D-printed brackets provide a secure fit. Rust-resistant hardware is included for longevity. While in use, the enclosure effectively contains a significant portion of fumes and smoke when used alongside an appropriate exhaust setup. Over time, some soot may accumulate on the laser and enclosure, necessitating occasional cleaning. For a more robust and professional feel, we recommend opting for the thicker panels.



Rad Features of Our Enclosure:

Our enclosure offers special features commonly found in professional-grade lasers. The laser filtering acrylics, with their amber color, substantially reduce light flashing into the room, resulting in an improved operating experience. Assembly is hassle-free and only requires a screwdriver and allen wrench. The panels are designed to fit snugly around the frame while providing ample height to accommodate the rotary and extension accessories. Convenient ports at the base allow easy insertion of sheet substrates, facilitating fast material changes and enabling tiling of jobs for infinite length projects.










Who We've Worked With

3d printer enclosures for business, education, universities.




About Clearview:

Clearview is a California-based artisan design studio that takes pride in producing our enclosures in-house, located in Sacramento. We prioritize craftsmanship



~~Q&A updates~~

Do the laser filtering panels mean I don't need to wear those amazingly rad safety glasses?

No, While the panels filter UV light at the wavelength that diode lasers operate at, we still suggest you wear those sexy safety glasses.

What is or is not included?

Generally speaking, if you pick the minimum price kit it include acrylic panels and hardware, and you 3D print the brackets and parts. If you choose to include 3Dprinted parts you will have everything you need to set up the enclosure, but you'll need to add your own exhaust fan and hose. We consider this a complete operating kit and the remaining customizations are optional. In all cases you will need to supply a 4" dryer hose to exhaust fumes to the window.

Will your XTool enclosure allow enough vertical space to use the rotary too also?

Yes! The inside height of the enclosure is 11.75" With feet attached and laser head fully articulated up there is just enough room. We also developed an easy to attach  wire lead that helps prevent the laser head wires from bushing on the enclosure lid. In all, this should give enough clearance for engraving onto an 80mm glass or tumbler.

Do you Ship internationally?

Yes. The shipping costs are automatically calculated at checkout. We ship using USPS/UPS/Fedex with an HS code of 8538.10. Shipping prices with express shipping services often cover import fees and bonds however additional fees, VAT, and other tariffs maybe charged.

What is your timeline?



We are shipping Preorder by January 15th or sooner.

Do the Laser filtering panels allow me to stare at the laser?

No. Independent testing shows the laser filtering panels block wavelengths up to 520nm (desktop Diodes operate at 445nm). However, it is never safe to look directly at the laser. Proper eye protection should be worn when you laser is in use. If you need and enclosure that meets ANSI, ASTM, or OSHA guidelines please contact us.

Does the enclosure have an exhaust port to clear smoke and fumes?

Our enclosure includes a USB powered Fan and is great way to keep the smoke and smell contained. The powered fan that is included will help a hobbyist reduce the fumes when you use a 4 inch exhaust hose outside. The USB fan is designed for casual hobby use. If you are burning large jobs or sensitive materials you may need to add an inline vent fan to your exhaust for more air circulation. You will need to supply 4" dryer hose. It is availble at most hardware store or amazon for about $10

Do you Make an enclosure for other models than just XTool?

Yes, we offer a universal option that is compatible with other laser engravers with an approximate 40cmx40cm engraving space here

Have a different laser engraver or desktop CNC? We make enclosures for several printer models. Just ask!

What is your return Policy?

We have a 30 day return policy. Unused, undamaged panels that still have the masking fully attached are eligible for a full refund less return shipping. If panels are damaged (after shipment) or the protective mask layer has been removed, we cannot offer a refund. For best results in ensuring fitment and to ensure you like the setup of our enclosures consider at least partially assembling with the mask on. If you find out it isn't for you, this allows to get the return for a full refund.



What are some other things I should know?

This listing is for the Clear acrylic panels, hardware, and printed parts to enclose your Xtool D1 Laser Engraver. Laser engraver not included.

"I still smell smoke" - A few things 1. The enclosure is designed to catch most of the fumes, but it is not sealed. You may wish to create your own mods for better sealing. 2. You may need more exhaust power or efficiency. Consider upgrading your fan to an inline fan or a fan with additional power.

We make updates and upgrades to our enclosures often. The brackets, placement, descriptions, and photos can change. Sorry, but if we've outdated a piece or feature we cannot roll that back for you.
