Probe Sonicator Sound Enclosure — Large | Qsonica Q500/Q700, Branson SFX250/SFX550

Branson's version of this is $3,240. Qsonica's is $995.

Both are a lined plastic box with a door and a slot in the top. The spread between them is distribution, not engineering.

We cut plastic panels for a living, so here is ours — thirty inches of interior height, sized for the big converters.

What it is for

A 20 kHz probe at full amplitude is a high-frequency screech that empties a shared room. It is an occupancy problem before it is a hearing problem: the person three benches away stops working. Second job — probe sonication of biological samples generates aerosol, and a closed box with a latched door is the standard engineering control.

How it works, mechanically

Two mechanisms in series. Mass blocks transmission through the panel. Absorption — open-cell foam across the interior — kills the reverberant buildup that would otherwise leak straight back out through the seams. Neither works without the other, and neither works at all if the box leaks.

Where these usually fail, and what we do about it

Seam leakage. A bracket-and-panel enclosure has continuous seams, and an unsealed seam hands you a fraction of the reduction you paid for. Every joint gets closed-cell gasket tape, and the door gets a compression latch, not a magnet — a magnet holds a door shut, it does not pull it into a gasket. That detail decides whether the product works.

Specification

• ✅ Interior 13" W × 13" D × 30" H — fits Qsonica Q500 and Q700, Branson SFX250 and SFX550, Branson Sonifier 250 and 450, Sonics Vibra-Cell VCX500 and VCX750
• ✅ CNC-cut panels on the Clearview bracket system, closed-cell gasket at every seam
• ✅ Full-height hinged door with compression latch and a clear viewing panel
• ✅ Gasketed converter slot in the top panel, with an internal support rod for the horn
• ✅ Side tubing ports for coolant lines and a thermocouple
• ✅ Open-cell foam lining across the full interior
• ✅ Flat-packed. Assembly is 60–120 minutes with the included hardware

Straight talk about numbers

Other vendors publish a dB figure. We do not, because we have not measured ours. We will tell you precisely what it is built from — panel thickness, gasket type, foam, latch mechanism — and let you judge it on construction. If you need a verified attenuation figure for an EHS file, buy from a vendor who has tested and published one. We are not going to invent a number to win an order.

Who buys this

Frequently someone who picked up a used Branson, Misonix or Sonics unit on LabX without the original enclosure and now has a screaming instrument in shared space. That buyer cannot get a $3,240 line item approved but can put this on a P-card. Also university EHS, after somebody complains.

Built in Rocklin, California. Lead time on standard kits is 10 business days or less. One-year warranty, 30-day returns, and a 100% satisfaction guarantee.
